FC-88R
VHF FM TRANSCEIVER
・Robust Body
・HEAVY DUTY USE
・Full Feature equipped
spec
| General | FC-88R |
|---|---|
| Frequency Range | 136-174MHz / 400-438MHz |
| Memory Channels | 128 |
| Channel Spacing | 2.5/5/6.25/10 12.5/25kHz |
| Frequency Stability | ±2.5ppm |
| Antenna Impedance | 50Ω |
| Battery Capacity | 1800mAh |
|---|---|
| Battery Voltage | 7.4V DC ±10% |
| Dimensions | 59 x 111 x 37mm |
| Weight with battery | 238g |
| Water Dust Proof | ─ |
| Receiver | |
|---|---|
| Sensitivity (12dB SINAD) | -122dBm |
| Adjacent Channel Selectivity | 60dB |
| Intermodulation | 60dB |
| Spurious Rejection | 65dB/60dB |
| Audio Output `<5% Distortion |
1W |
| Transmitter | |
|---|---|
| Output Power | 5W/1W |
| Max. Frequency Deviation | ±5kHz/±2.5kHz |
| Adjacent Channel Power | ≦-65dB/≦-60dB |
| Spurious and Harmonics | -60dB |
