FT-42X
VHF FM TRANSCEIVER
・Wide / Narrow band
・50 groups CTCSS,
105 groups of standard DCS
・Time-out timer (TOT)
・Busy channel lockout (BCL)
・Programmable by PC
・Battery saving function
spec
| General | FT-42X |
|---|---|
| Frequency Range | 400-470MHz |
| Memory Channels | 16 |
| Channel Spacing | W/N |
| Frequency Stability | ±2.5ppm |
| Antenna Impedance | 50Ω |
| Battery Capacity | 1500mAh |
|---|---|
| Battery Voltage | 3.7V DC |
| Dimensions | 54 x 135 x 21mm |
| Weight with battery | 113g |
| Water Dust Proof | ─ |
| Receiver | |
|---|---|
| Sensitivity (12dB SINAD) | -120dBm |
| Adjacent Channel Selectivity | 55dB |
| Intermodulation | 65dB |
| Spurious Rejection | 60dB |
| Audio Output `<5% Distortion |
500mW |
| Transmitter | |
|---|---|
| Output Power | 2W |
| Max. Frequency Deviation | ±5kHz |
| Adjacent Channel Power | -65dB |
| Spurious and Harmonics | -60dB |
